OPTICS spotlights
Controlled-optic spotlights in 9 catalogue sizes and 5 to 30 W. Two profile sections —35 × 80 and 47 × 37 mm— with adjustable and wall-washer versions.
- 5 – 30 W
- Power range
- 12
- Models
- 9
- Catalogue sizes
- 12
- Codes in the series
The models
12 groups across two mountings. The catalogue declares where each one goes: 6 stay in view and 6 are recessed.
In view
In view: on the slab or hung on wire, with the body as part of the space.
6 codes| Model | Dimensions | Optic | Power | Codes |
|---|---|---|---|---|
| LC3580H1 | 140 mm | Not declared | 10 – 10 W | 1 |
| LC3580H2 | 275 mm | Not declared | 20 – 20 W | 1 |
| LC3580H3 | 403 mm | Not declared | 30 – 30 W | 1 |
| LC3580W1 | 1 mm | Not declared | 5 – 5 W | 1 |
| LC3580W2 | 2 mm | Not declared | 10 – 10 W | 1 |
| LC3580W3 | 3 mm | Not declared | 15 – 15 W | 1 |
Recessed
Integrated into the ceiling, body hidden and only the light in view.
6 codes| Model | Dimensions | Optic | Power | Codes |
|---|---|---|---|---|
| LR4737H1 | 150 mm | Not declared | 10 – 10 W | 1 |
| LR4737H2 | 280 mm | Not declared | 20 – 20 W | 1 |
| LR4737H3 | 415 mm | Not declared | 30 – 30 W | 1 |
| LR4737W1 | 150 mm | Not declared | 10 – 10 W | 1 |
| LR4737W2 | 280 mm | Not declared | 20 – 20 W | 1 |
| LR4737W3 | 415 mm | Not declared | 30 – 30 W | 1 |
The model names read directly: 3580 and 4737 are the profile section in millimetres, H is the adjustable spot and W the wall washer, and the final digit is the number of heads.
Optics and distribution
What sits in front of the LED. The diffuser is declared in position 10 of the code and the lens variant in position 13: two separate axes that together drive output and glare control. The three lens angles are the same 5 codes, ordered in whichever aperture suits.
- 15° 15° lens Accent, double height 5 codes L1 / L2 · var.
- 30° 30° lens Circulation and retail 5 codes L1 / L2 · var.
- 45° 45° lens General, mid height 5 codes L1 / L2 · var.
Polar curve
Luminous intensity distribution of each optic, seen in section. This is the shape of the beam: where the light falls and in what proportion to the peak.
- Optic
- Lente 15° 15° lens 15°
- Lente 30° 30° lens 30°
- Lente 45° 45° lens 45°
Published as a percentage rather than in candelas on purpose: the curve describes the shape of the optic, which is what you choose at series level. Absolute candelas depend on length, diffuser and colour temperature, and belong in the IES file for the code.
Colour of the light
12 of the 12 codes in the series declare a colour temperature in the catalogue.
- 3000 K Warm
- 4000 K Neutral
- 5000 K Cool neutral
- 6000 K Cool
- Tunable White (Color Changing) Tunable on site
Dimming
Most of the series is quoted in ON-OFF, DALI and 0-10 V. It is defined at order time: the driver is fitted at the factory and cannot be swapped on site.
- ON/OFF
- No dimming. The base method on every code.
- DALI
- Addressable per luminaire, scenes and sensors.
- 0-10 V / 1-10 V
- Analogue, with separate control wiring.
- Color Changing
- Colour temperature shift, on 3 codes in the series.
- Driver sin parpadeo
- Osram non-flicking on 2 codes, for spaces where video is recorded.
Technical specifications
Values for the complete series, taken from the catalogue. For a specific code, the datasheet gives the exact figure.
Photometry
| Efficacy | 40 · 70 · 100-130 lm/W (±5%) |
|---|---|
| Colour temperature | |
| |
| Colour rendering | Ra > 82 · Ra > 90 |
| Beam angle | 15° · 30° · 45° with lens variant |
Electrical
| Power | 5 – 30 W |
|---|---|
| Input voltage | 220 – 240 V · 50/60 Hz |
| LED chip | Everlight 2835 · Osram 3030 |
| Driver | Color Changing · ON-OFF / 1-10V / DALI / Color Changing · OSRAM ON/OFF / Color Changing · Osram / Color Changing · Osram ON-OFF / Color Changing · Euchips / Color Changing |
Construction
| Body | Aluminium |
|---|---|
| Sizes | 9 catalogue sizes |
| Diffusers and optics | 15° lens · 30° lens · 45° lens |
| Finishes | |
Colour is indicative on screen. To specify, ask for the physical sample. | |
Installation and life
| Warranty | 5 years |
|---|---|
| Ingress protection | IP20 |
One code, one exact product
Every attribute that defines a variant, in a fixed order of 15 positions. No ambiguity in quotes, purchase orders or specifications.
- CMX 01
- XL 02
- W1 03
- 3580 04
- 1 05
- T5 06
- 220240 07
- 8 08
- 30 09
- X 10
- SFC 11
- X 12
- W1 13
- W 14
- 5 15
See the full map of the code
- 01 CMX Brand Cromatix
- 02 XL Series XLine
- 03 W1 Model W1
- 04 3580 Profile 3580 mm
- 05 1 Size 1 mm
- 06 T5 Chip Everlight 2835
- 07 220240 Voltage 220-240 V
- 08 8 CRI Ra ≥ 80
- 09 30 CCT 3000 K
- 10 X Diffuser Not applicable
- 11 SFC Mounting Surface
- 12 X Control Not at this level
- 13 W1 Variant Wall washer 1
- 14 W Finish White
- 15 5 Power 5 W
X means the position does not apply or there is no data: the code always keeps its 15 positions so it stays machine-parseable. Colour temperature is the first two digits of the Kelvin value, and power carries no leading zeros.
Representative configurations
Real catalogue codes, chosen to cover the range of the series: three lengths of the profile with most codes, plus dual emission, the lens and the emergency kit. Flux is power times efficacy from the catalogue itself; where efficacy is a range it is left blank.
| MODEL_CODE | Model | Dimensions | Power | Flux | Efficacy | CRI |
|---|---|---|---|---|---|---|
| CMX-X-H1-X-140-X-220240-9-30-X-WAL-X-H1-W-10 | LC3580H1 | 140 × 35 × 80 mm | 10W | 700 lm | 70lm/W | > 90 |
| CMX-X-H2-X-275-M0-220240-9-30-X-WAL-X-H2-W-20 | LC3580H2 | 275 × 35 × 80 mm | 20W | 1.400 lm | 70lm/W | > 90 |
| CMX-X-H3-X-403-M0-220240-9-30-X-WAL-X-H3-W-30 | LC3580H3 | 403 × 35 × 80 mm | 30W | 2.100 lm | 70lm/W | > 90 |
| CMX-XL-W1-3580-1-T5-220240-8-30-X-SFC-X-W1-W-5 | LC3580W1 | 138 × 35 × 80 mm | 5W | — | 100-130lm/W | > 82 |
| CMX-XL-W2-3580-2-T5-220240-8-30-X-SFC-X-W2-W-10 | LC3580W2 | 270 × 35 × 80 mm | 10W | — | 100-130lm/W | > 82 |
| CMX-XL-W3-3580-3-T5-220240-8-30-X-SFC-X-W3-W-15 | LC3580W3 | 408 × 35 × 80 mm | 15W | — | 100-130lm/W | > 82 |
Photometry and documentation
Photometry is a measurement, not a description: an IES or LDT file corresponds to one physical configuration and changes with length, optic, diffuser and colour temperature.
That is why we do not publish a single series-wide file. Tell us which configuration you are evaluating and we will send the right one, together with the datasheet for that code.
OPTICS in project
Frequently asked questions
What is the difference between the H and W versions?
H is the adjustable spot, for accenting an object. W is the wall washer, with the optic tilted to spread light evenly over a vertical surface.
Do they mount inside an XLine profile?
Yes. Both sections —35 × 80 and 47 × 37 mm— are XLine sections, so the spotlights mount within the same run as the light line.
How many heads does each one carry?
One, two or three, and the last digit of the name says which: the 3580H3 is the 35 × 80 adjustable one with three heads.
How do I get the photometry for a Dialux calculation?
Write to us with the complete MODEL_CODE and we will send the matching IES or LDT file.
Tell us about the project
If the requirement is already defined, the length and colour temperature are enough to reach a concrete proposal. If you are still exploring, we start from what the light has to resolve.
